Switchpack 6 ch LS 3 kw, 32A in, Soca+Schuko out, DMX5

Description

Product Features :

? 6×3kW switching output
? DMX512 input, opto-isolated protection
? LCD display
? MCB overload and short-circuit protection
? 3-phase indicator and communication status LEDs
? Intelligent control of fans and over-heat warning

Technique Parmeters:
? Power supply:3NPE 400V 50HZ TN-S system
? Power supply voltage range:230V±10%
? Rated supply current:60A per phase at 230V
? Control signal protocol:DMX-512/1990 USITT
Standards Compliance:
? EMC:EN55015
? Safety:EN60204-1:2006 EN60950-1:2006
Mechanical Data:
? Dimensions(mm):483(W)×132(H)×460(D)
? Net weight:17Kg
