Node, Ethernet Switch Gigabit 8 port, Luminex, Ethercon

Description

The Luminex GigaSwitch 8 Ethernet Switch is a truss mountable device equipped with eight Neutrik Ethercon ports providing 10/ 100/ 1000 Mbps bandwidth.
These ports can be used for connecting PCs, Media servers, ArtNET or sACN nodes.
The eight multi-speed ports use standard twisted pair cabling and are ideal for segmenting networks into small, connected SubNets. Each port can support up to 2000 Mbps of throughput in full-duplex mode. This stand-alone GigaSwitch enables the network to use most multimedia and imaging applications concurrently with other user applications without creating bottlenecks.

Features:
Eight 1000 Base-T Gigabit Ethernet ports on Neutrik Ethercon
Supports Auto-negotiation for 10/100/1000Mbps and Duplex mode
Supports Auto-MDIX for each port
Supports Full/Half duplex Transfer mode for 10 and 100Mbps
Supports fill Duplex transfer mode for 1000Mbps
Full Wire Speed Reception and Transmission
Store and Forward switching method
Supports 4096 absolute MAC adresses
Side Panel with diagnostic LEDs
2 x M10 Inserts (28mm deep) for truss clamp (top, right, bottom)
