Fresnel 1 kW Arri ST 1, Pole Operated Tapp + krok, Schuko Black

Description

The Arri ST True Blue Series of tungsten Fresnel lighting fixtures represents a major update of this well-known industry standard. Feedback from respected lighting professionals combined with advances in technology enable Arri to present a selection of Fresnels with over 30 new improvements for studio and location lighting.

Reduced weight, compact size and maximum light output are the most obvious improvements. Arri's patented cross-cooling system, which encourages a stream of air to pass around the Fresnel lens and into the lamphead from the front, has reduced the lamp housing temperature of True Blue units by 25% and the lens temperature by 17%.

When fitted with a 1000 watt bulb (available separately), this fixture will provide a 13°, 3' (0.9 m) wide beam of 532 fc from a distance of 13.2' (4 m) at full spot. At full flood, it will throw a 94.5 fc beam 57°, (4.3 m) wide from the same distance.

Pole Operated
Tilt, focus and pan are pole operated safely from the studio floor (pole available separately)
Improved Maintenance
Simplified access to internal components
Smooth lamp housing surfaces are now easier to clean

Rating 1000 Watts, 120-230VAC
Socket (Lampholder) G22 Single End, Bi Post
Lens (Condenser) 7" (17.5cm) Low expansion borosilicate
Reflector (Mirror) Spherical specular high purity aluminum
Mounting Included pipe clamp
Yoke Tubular twin fork
Cable 36" (0.9 m) No switch, bare leads
Focusing Front and rear mount knobs
Weight 18.7 lbs (8.5kg)
Dimensions 13.1 x 21.9 x 12.4" (33.3 x 55.5 x 31.5cm) (WxHxD) including yoke
